Plan your UniFi Power Distribution Hi-Density installation in Perth with Servicewest. We assess the site and supporting equipment before specifying USP-PDU-HD.
We review what USP-PDU-HD needs to do within your property and which UniFi applications or supporting devices it requires. Existing network capacity, mounting, account access and the Australian model are checked before the equipment list is finalised.
Power Method: 100–125V AC, 30A Max. (Derated to 24A), 50/60 Hz (NEMA L5-30P). Networking Interface: (1) 10/100 MbE RJ45 port (3) GbE RJ45 ports for network redundancy. Dimensions: 1485 x 55 x 56 mm (58.5 x 2.17 x 2.2"). Ambient Operating Temperature: 0 to 40° C (32 to 104° F). These manufacturer figures inform the mounting, connection and site assessment; we check the final model and supporting equipment before installation.
Power connections, the intended load and the required backup function determine suitability. Runtime varies with the connected equipment and battery condition. We confirm the Australian configuration and installation responsibilities before specifying the unit.
Configuration and testing cover the functions agreed for this installation. We explain the controls and assign ownership of routine administration, updates and any backup responsibilities. Supporting equipment is selected for this exact model.
Manufacturer specifications for USP-PDU-HD. Check the selected model, regional version and current software requirements during assessment.
View manufacturer source| Dimensions | 1485 x 55 x 56 mm (58.5 x 2.17 x 2.2") |
|---|---|
| Weight | 6.3 kg (13.9 lb) |
| Enclosure Material | SGCC steel |
| Management | Ethernet |
|---|---|
| Networking Interface | (1) 10/100 MbE RJ45 port (3) GbE RJ45 ports for network redundancy |
| Power Method | 100–125V AC, 30A Max. (Derated to 24A), 50/60 Hz (NEMA L5-30P) |
| Power Output | (24) Power control outlets: Per Bank (Bank1: port 1 to 12, Bank2: port 17 to 28): Rating output current: 12A at 125V AC (1500W) Max. output current: 15A at 125V AC (1875W) Total: Rating output current: 24A at 125V AC (3000W) Max. output current: 30A at 125V AC (3750W) (4) USB type C ports: 5VDC 2A per port, total 20W Max. power |
| ESD/EMP Protection | Air: ± 8kV, contact: ± 4kV |
| Display | 1.3" touchscreen |
| Buttons | (1) Factory reset (1) Circuit breaker |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC |
| Mobile Apps | UniFi iOS™ and 10.11.0 and later Android™ 10.11.0 and later |
|---|---|
| UniFi Network | Version 8.0.24 and later |
Related catalogue items to discuss. Compatibility is checked against the exact model and site design.
